Product
Hardness 60 Black fire retardant neoprene
Polymer: Neoprene rubber
Color: Black
Thickness: Thickness ranges from 1mm to 100mm; above 15mm offered in sheet form.
Standard Size:
Width: 1mtrs 1.2mtrs 1.4mtrs 1.5mtrs 1.6mtrs 1.8mtrs 2.0mtrs
Length: 5mtrs 10mtrs 15mtrs 20mtrs; Custom dimensions available upon request.
Surface: Both sides smooth, or one/both sides with cloth, or one side with anti-slip texture.
Customizable Shapes: Roll / Sheet / Strip
Embedding layer: Nylon canvas / Mesh fabric / Nylon mesh fabric / Encrypted canvas
Packing Info: Custom packing includes plastic film, PP bags, and pallets.
Color, logo, and labels or special markings can be customized upon request.
Fire Retardant Neoprene Rubber Performance Parameters & Specification
| Code | Specific Gravity | Hardness | Tensile Strength | Elongation at Break |
| ZXZRS20107FR-60 | 1.6g/cm³ | 60+/-5 Shore A | 5Mpa | --- |
| Thickness | Width | Length | Insertion | Weight |
| 1 | 1.2m | 10m | / | 15.36kgs/m² |
| 2 | 1.2m | 10m | 1PLY | 34.56kgs/m² |
| 3 | 1.2m | 10m | 1PLY | 53.76kgs/m² |
| 4 | 1.2m | 10m | 1PLY | 72.96kgs/m² |
| 5 | 1.2m | 10m | 2PLY | 92.16kgs/m² |
| 6 | 1.2m | 10m | 3PLY | 111.36kgs/m² |
| 7 | 1.2m | 10m | 3PLY | 130.56kgs/m² |
| 8 | 1.2m | 10m | 4PLY | 149.76kgs/m² |
| 10 | 1m | 10m | 5PLY | 160kgs/m² |
| 12 | 1m | 10m | 8PLY | 192kgs/m² |
| 15 | 1m | 2m | 10PLY | 48kgs/m² |
| 20 | 1m | 2m | 10PLY | 64kgs/m² |
| 25 | 1m | 2m | 10PLY | 80kgs/m² |
1. All specifications and dimensions above are subject to standard ± tolerances.
2. All data are provided as typical values within specified ranges; actual available specifications may vary depending on standard production grades.
3. This data sheet applies only to the rubber sheet products listed in the table. Other specifications can be manufactured upon request.
4. The weights provided in the table are theoretical values, actual product weights may vary due to production tolerances. In the case of customized rubber sheets, variations in width, length, thickness, or other specified parameters will impact the final weight. For reference only.
Chemical Properties
| Polymer Content | ZXZRS20001PC-20% | ZXZRS20001PC-30% | ZXZRS20001PC-50% | ZXZRS20001PC-70% | ZXZRS20001PC-100% |
| Aliphatic Hydrocarbons | Regular | Regular | Excellent | Excellent | Excellent |
| Aromatic Hydrocarbons | Regular | Regular | Excellent | Excellent | Excellent |
| Lubricating Oils | Regular | Regular | Regular | Regular | Excellent |
| Outdoor Exposure | Regular | Regular | Regular | Excellent | Excellent |
| Ozone Exposure | Regular | Regular | Regular | Excellent | Excellent |
| Diluted Acids | Regular | Regular | Regular | Excellent | Excellent |
| Diluted Alkali | Regular | Regular | Regular | Excellent | Excellent |
| Vegitable Oil | Poor | Poor | Regular | Excellent | Excellent |
| Animal Oil | Poor | Poor | Regular | Excellent | Excellent |
Note:
1. The chemical resistance values provided are intended as general reference only, based on standard laboratory conditions.
2. Actual performance may vary depending on chemical concentration, temperature, exposure time, and specific working conditions.
3. It is the responsibility of the user to verify material compatibility before application.
4. The manufacturer assumes no liability for damages or failures resulting from improper material selection or usage conditions.
5. Detailed technical advice are available upon request.
Tianjin China Rubber Co.,Ltd produces fire retardant neoprene sheets specifically developed for use in safety-critical applications. These rubber sheets are formulated with halogen-free flame suppressants to minimize smoke and combustion risk during thermal exposure.
The material maintains excellent structural integrity in conditions where moderate heat and flame resistance are required. Typical uses include protective barriers in public transit interiors, control panels, electronic housings, and industrial gaskets.
This fire retardant neoprene offers good tensile strength and durability while resisting oils, mild chemicals, and weather aging. Its consistent hardness and low compression set make it suitable for sealing, padding, and vibration insulation in fire-sensitive zones.
Sheets are available in standard and customized dimensions. The uniform density and smooth surface of each fire retardant neoprene sheet help ensure precise fitting during installation and long-term performance in both static and dynamic environments. All products from Tianjin China Rubber Co.,Ltd are manufactured under stringent quality standards and fully certified to SGS, RoHS 2.0, and REACH requirements.
